Description
Samsung DE31-10170A turntable motor for microwave ovens.
The microwave turntable motor is a synchronous motor so the turntable can turn is either direction. The microwave turntable motor uses a built in gearbox to drive the turntable tray via the microwave turntable coupling.
Alternative marking M2LJ24ZS52
Part number: DE31-10170A or DE31-10170B
Specifications:
Voltage = 230 volts AC
Frequency = 50-60 Hz
Rotation speed = 2.5-3 RPM
Power consumption = 2.5-3 W
Connections = 4.6 mm terminals
Drive shaft length = 13 mm
The drive shaft may be made from either nylon or steel
Drive shaft diameter 7 mm "D" shaped cross section
Suitable for - amongst others, the following models :
| A2137RVS/E03 | CE1185UB |
| BCE1196T-B/XEF |
CE1185UB/XEF
|
| BCE1196TBXEF | CE118KF |
| C100-5/XEF | CE118KFM |
| C101/XEF |
CE118PE-X1/XEN
|
| C103-5-XEN |
CE118PPTX1/XEF
|
| C104F-SL/XEF |
CE118PT-B1/XEF
|
| C104F/XEF |
CE118PT-X1/XEN
|
| C105 |
CE1190/XEF
|
| C105-5/XEF |
CE1190XEN
|
| C105-5S/XEF |
CE1191TXEN
|
| C105/XEF |
CE1196T-B/XEF
|
| C107AT |
CE1196T-S/XEF
|
| C107AT-5/XEF | CE1196TB |
| C107F |
CE1350-S/XEN
|
| C107F-5/XEF |
CE1351T-S/XEN
|
| C107F/XEF |
CE137NE-S
|
| C108ST5XEN |
CE137NE-S/XEF
|
| C108STT |
CE137NEM
|
| C108STT-5/XEF |
CE137NEM-S/XEF
|
| C108STT/XEF |
CE137NEM-S/XEN
|
| C131-SL/XEN |
CE137NEM-X/XEF
|
| C131/XEN |
CE137NEM-X/XEN
|
| C131T-SL/XEN | CE137NES |
| C131T/XEN |
CE137NM-B/XEN
|
| C138ST/XEN |
CE137NM-S/XEN
|
| C138STT |
CE137NM-X/XEN
|
| C138STT/XEF |
CE137NM/XEN
|
| CE1000-T/XEF |
CE137NT/XEF
|
| CE1000-TB/XEF |
CE73J-W/XEN
|
| CE1000SXEN | CK135 |
| CE1000T-S/XST | CK135M |
| CE1000TSXEN | CK136T |
| CE1000TXEN |
CK136T/XEF
|
| CE1000XEN | CK138FM |
| CE100V-S/XEN | CK139FS |
| CE100V-W/XEN | CK910 |
| CE1050 | CK910N |
| CE1050-S | CK95 |
| CE1050-S/XEF | CK95/XEN |
| CE1050/XEF |
CK98F/XEN
|
| CE1052AT-S/XEF |
CK99FS/XEF
|
| CE1052AT/XEF |
CP1370-B/XEN
|
| CE106KT | CP1370E |
| CE1071 |
CP1370E-B-XEG
|
| CE1071-S/XEF |
CP1395-B/XEF
|
| CE1071/XEF |
CP1395-EST
|
| CE1071SXEC |
CP1395-S/XEN
|
| CE1071SXEN | CP1395E |
| CE1071XEN |
CP1395E-B/XET
|
| CE107B |
CP1395E-S/XEF
|
| CE107B-B/XEF |
CP1395EST/XEF
|
| CE107B-S/XEF |
CST1660ST
|
| CE107B/XEF |
CST1660ST/XEN
|
| CE107F |
CST1660WT/XEN
|
| CE107F-S | fw113t002 |
| CE107F-S/XEF |
FW113T002/XEF
|
| CE107F-S/XEN |
MAG675RVSP01
|
| CE107FS |
MAG675RVSP02
|
| CE107FT-B |
MC285TATCSQ
|
| CE107FT-B/XEG |
MC285TATCSQ/EN
|
| CE107FT-S/XEF |
MC28H5015AK
|
| CE107FT-S/XEN |
MC28H5015AK/EF
|
| CE107M |
MC28H5015AS/EN
|
| CE107M-3S/XEN |
MC28H5015AW/EF
|
| CE107M-4S/XEN |
MC28H5015CK/EF
|
| CE107M-S/XEF |
MC28H5015CS
|
| CE107MBXEN |
MC28H5015CS/EN
|
| CE107MST-3/XEN |
MC28H5015CW/EF
|
| CE107MST-4/XEN |
MC28H5125AK
|
| CE107MT-4B/XEF |
MC28H5125AK/EF
|
| CE107MT/XEF |
MC28H5125AW/EF
|
| CE107MTST/XEF |
MC28H5125CK
|
| CE107V |
MC28H5125CK/EN
|
| CE107V-W/XEF |
MC28H5125CW
|
| CE107V/XEH |
MC28H5125CW/EN
|
| CE109MTST1 |
MC28H5135CK/EF
|
| CE109MTST1/XEG |
MC32F604TCT
|
| CE1100SXEG |
MC32F604TCT/EN
|
| CE1100SXEN |
MC32F606TCT
|
| CE1100XEN |
MC32F606TCT/EG
|
| CE1101TXEN |
MC32F606TCT/EN
|
| CE1140/XEF |
MC32J7035AK
|
| CE1141T |
MC32J7035AK/EN
|
| CE1141T-S/XEF |
MC32J7035AS
|
| CE1141T/XEF |
MC32J7035AS/EN
|
| CE1150-S/XET |
MC32J7035AW
|
| CE1150/AND |
MC32J7035AW/EN
|
| CE1150R-S/SBW |
MC32J7055CT
|
| CE1150R-U/BWT |
MC32J7055CT/EN
|
| CE1150RBWT |
MC32K7055CK
|
| CE1150RSBW |
MC32K7055CK/EN
|
| CE1150SXEN |
MC32K7055CT
|
| CE1151T |
MC32K7055CT/EN
|
| CE1151T-S/XEF |
MC32K7085KT
|
| CE1151T/XEF |
MC32K7085KT/EN
|
| CE1151TSXEN |
MC35J8055
|
| CE115K |
MC35J8055CK
|
| CE115KC/XEE |
MC35J8055CK/EF
|
| CE115KSR/BWT |
MC35J8055CK/EN
|
| CE115P-X/ZAM |
MC35J8055CKEF
|
| CE115PE-X/XSG |
MC35J8055CWEN
|
| CE115PEXXEN |
MC35J8055KTEN
|
| CE115PTXXEN |
MC35J8085CTEN
|
| CE115PXXEN |
MC35J8085LT/EF
|
| CE116KT |
MC35J8085LTEN
|
| CE116KT(SKW) |
MC35J8088LTEN
|
| CE117ABXEN |
MC455TBRCBB
|
| CE117AE-X/XEF |
MC455TBRCBB-EN
|
| CE117AE/XEF |
MC455TBRCBB/EN
|
| CE117AESXEN |
MC455TBRCSR
|
| CE117AEXXEN |
MC455TBRCSR-EN
|
| CE117APT-B/XEF |
MC455TBRCSR/EN
|
| CE117ASXEN |
MC457TDRCBB
|
| CE117AT-X/XEF |
MC457TDRCBB/EN
|
| CE117AXEN |
MC457TDRCSR
|
| CE117AXXEN |
MC457TDRCSR/EN
|
| CE117P-X1/XEN |
MC457TDRCSREN
|
| CE117PFC-X/SWS |
MG23K3575AK
|
| CE117PT-B/XEO |
MG23K3575AK/EN
|
| CE117PT-X1/XEN |
MG23K3575AS
|
| CE1180GWT |
MG23K3575AS/EN
|
| CE1180GWT/XEF |
MG23K3575AW
|
| CE1180GWTXEN |
MG23K3575AW/EN
|
|
CE1180UBTXEN
|
